Dishwashers are a great convenience, saving time and effort when it comes to cleaning dishes. However, when something goes wrong, it can be frustrating and inconvenient. One issue that may arise with an Electrolux dishwasher is an error code. These codes can indicate a variety of problems, from minor issues that can be easily fixed to more serious problems that require professional repair.
In this article, we will cover some of the most common Electrolux dishwasher error codes, what they mean, and how to troubleshoot them.
Electrolux Dishwasher Error Codes
| Error Code | Meaning | Solution |
|---|---|---|
| E1 | Heating Issue Detected | Check the heating element and thermostat. Ensure proper water temperature (at least 120°F). |
| E3 | Water Heating Problem | Inspect the heating element for damage. Verify wiring connections to the heater and control board. |
| E4 | Water Overflow Error | Check the float switch and ensure it’s not stuck. Inspect the water inlet valve for leaks. |
| E6 | Water Sensor Error | Clean the water sensor. Replace if error persists. |
| E7 | Flow Meter Error | Check the flow meter for blockages or damage. Replace if faulty. |
| F1E1 | Electronic Control Board Failure | Reset by unplugging for 5 minutes. Replace control board if issue remains. |
| F2E2 | User Interface Error | Check control board and interface connections. Replace interface if needed. |
| F3E2 | Temperature Sensor Error | Test with multimeter. Replace sensor if not functioning. |
| F4E3 | Circulation Pump Failure | Inspect for clogs. Replace pump if damaged. |
| F6E1 | Low/No Water Entering | Ensure supply valve is open. Check inlet valve and hose. |
| F6E3 | Suds or Air in Water Pump | Use correct detergent. Run rinse cycle to clear suds. |
| F6E4 | Float Switch Open | Check if float is stuck. Ensure no debris around switch. |
| F7E2 | Motor Failure | Inspect for damage. Replace if necessary. |
| F8E2 | Drain Pump Problem | Check for blockages. Replace if faulty. |
| F8E4 | Overflow Detected | Inspect float switch, inlet valve, and for leaks. |
| F8E5 | Water Hardness Sensor Error | Clean or replace sensor. Check wiring. |
| F9E1 | Diverter Valve Problem | Inspect for blockages. Replace diverter motor if defective. |
| F9E2 | Diverter Stuck | Check for obstructions. Replace if jammed or broken. |
| FAE5 / F10E5 | Vent Wax Motor Error | Test for continuity. Replace motor if faulty. |
| H2O | Low Water Supply | Ensure water supply is on. Check hose and valve for clogs. |
| 10 Pause 5 Pause | Control Board Error | Reset dishwasher. Check control board connections. |
| 1 Pause 1 Pause | Door Latch Error | Inspect door latch. Replace if faulty. |
| 6 Pause 1 Pause | Water Inlet Error | Ensure proper water flow. Check inlet valve. |
| 8 Pause 1 Pause | Drain Error | Clear drain blockages. Inspect drain pump. |
| 8 Pause 4 Pause | Water Level Sensor Error | Clean or replace sensor. |
| 8 Pause 5 Pause | Overflow Protection Error | Check for leaks. Inspect float switch. |
| 9 Pause 1 Pause | Diverter Motor Error | Inspect motor. Replace if needed. |
| All Cycle & Option Lights Flashing | Control Lock Active/System Error | Disable control lock. Reset dishwasher. |
| Clean Light Flashing | Heating Issue Detected | Check heating element. Ensure proper water temperature. |
| Control Light Flashing | Software/Control Error | Reset control board. Check wiring. |
| Sanitize Light Flashing | Sanitize Cycle Incomplete | Ensure hot water. Check heating element. |
How to Reset a KitchenAid Dishwasher Error Codes
- Press and hold the Start/Reset button for 5 seconds.
- Unplug the dishwasher or turn off the circuit breaker for 5 minutes.
- Turn the power back on and run a test cycle to check if the error is cleared.
- E10 – Water is not filling up properly
The E10 error code is caused by the dishwasher not filling up with water correctly. This can be due to a variety of issues, including a blocked or kinked water supply hose, a malfunctioning water inlet valve, or a faulty pressure switch.
To troubleshoot this error code, first, check the water supply hose for any kinks or blockages. If the hose is clear, then check the water inlet valve to see if it is working correctly. If the valve is faulty, it will need to be replaced.
- E20 – Drain filter is clogged
The E20 error code indicates that the dishwasher’s drain filter is clogged. This can prevent water from draining properly, leading to issues with the dishwasher’s performance.
To troubleshoot this error code, first, remove the dishwasher’s filter and check for any blockages. If the filter is dirty or clogged, clean it thoroughly and replace it. If the filter is clean and the error code persists, then there may be a problem with the dishwasher’s drain pump, which will require professional repair.
- E30 – The dishwasher’s door is not closing properly
The E30 error code is caused by the dishwasher’s door not closing correctly. This can be due to a faulty door latch, a misaligned door, or a malfunctioning control board.
To troubleshoot this error code, first, check the dishwasher’s door latch to ensure that it is functioning correctly. If the latch is faulty, it will need to be replaced. If the latch is working correctly, then check the door’s alignment to make sure it is closing properly. If the door is misaligned, it may need to be adjusted or repaired. If the door and latch are both functioning correctly, then there may be an issue with the dishwasher’s control board, which will require professional repair.
- E40 – The dishwasher’s door is open
The E40 error code indicates that the dishwasher’s door is open. This can be due to a faulty door latch or a malfunctioning control board.
To troubleshoot this error code, first, check the dishwasher’s door latch to ensure that it is functioning correctly. If the latch is faulty, it will need to be replaced. If the latch is working correctly, then there may be an issue with the dishwasher’s control board, which will require professional repair.
- E50 – The dishwasher’s motor is not functioning correctly
The E50 error code is caused by the dishwasher’s motor not functioning correctly. This can be due to a faulty motor, a malfunctioning control board, or an issue with the motor’s wiring.
To troubleshoot this error code, first, check the dishwasher’s motor to see if it is functioning correctly. If the motor is faulty, it will need to be replaced. If the motor is working correctly, then check the dishwasher’s control board to see if it is functioning correctly. If the control board is faulty, it will need to be replaced. If the motor and control board are both functioning correctly, then there may be an issue with the motor’s wiring, which will require professional repair.
FAQs
Q: Can I reset my Electrolux dishwasher to clear error codes?
A: Yes, you can reset your Electrolux dishwasher to clear error codes. To do this, first, turn off the dishwasher and unplug it from the electrical outlet. Wait for a few minutes, and then plug the dishwasher back in and turn it on. This should reset the dishwasher and clear any error codes that were previously displayed.
Q: What should I do if an error code persists after troubleshooting?
A: If an error code persists after troubleshooting, it may be necessary to contact a professional technician to diagnose and repair the issue. Continuing to use the dishwasher with an unresolved error code could cause further damage or safety hazards.
Q: Can I prevent error codes from occurring in my Electrolux dishwasher?
A: While it’s not always possible to prevent error codes from occurring, there are steps you can take to reduce the likelihood of them happening. Regularly cleaning and maintaining your dishwasher can help prevent issues with the filter, drain, and other components. Additionally, following the manufacturer’s guidelines for loading and running the dishwasher can help ensure it functions properly.
Conclusion
Electrolux dishwashers are a great convenience, but when an error code appears, it can be frustrating and inconvenient. Understanding the most common error codes and how to troubleshoot them can help you quickly resolve issues and get your dishwasher back up and running. If an error code persists or if you’re unsure how to troubleshoot a particular issue, it’s always best to contact a professional technician for assistance. Regular maintenance and proper use can also help prevent error codes from occurring in the first place.
